HDG Anti-Slip International Standard Steel Grating for Steel Platform/Walkway Mesh Panel/Flooring High Quality Carbon Steel Weld Bar Metal Grate
Place of Origin:China
Brand Name:GNEE
Certification:SGS
Minimum Order Quantity:10 square meter
Price:Negotiable
Payment Terms:Negotiable
Supply Ability:100 ton/week
Tags:
Product Details
Highlight:
anti-slip steel grating for platforms
,welded carbon steel grating panels
,international standard metal floor grating
Product Description
HDG Anti-Slip International Standard Steel Grating
Product Description
Steel bar grating has a vast amount of uses ranging from flooring and stairs to bridges and sewage drain covers. It is a smart choice for flooring and stairs in work areas where slipping and falling are a major concern, such as industrial plants, waste-water treatment facilities, or manufacturing operations. The open design makes bar grating the best option for areas that require the passage of light. It also works well for projects that require fast, easy fabrication and installation.
Applications
- Flooring
- Stairs, stair treads
- Sewage drain covers, manhole covers and loading ramps
- Racks and shelving
- Catwalks, Walkway and crossover platforms
- Safety steel grids fence
- Bridge sidewalks and bridge decking
- Architectural uses like building facades or partitions
- Security screens in residential and commercial buildings
Specifications
- Bearing Load bar: 25x3, 25x4, 30x3, 30x4, 30x5, 32x5, 35x5, 40x5, 50x5 to 75x10mm
- Bearing Load bar pitch: 12.5, 15, 20, 25, 30, 35, 40, 45, 60mm
- US standard: 1"x3/16", 1-1/4"x3/16", 1-1/2"x3/16", 1"x1/4", 1-1/4"x1/4", 1-1/2"x1/4" etc.
- Cross bar pitch: 40, 50, 100mm
- Surface finishing treatment: Untreated Black, Electric Galvanized, Hot Dipped Galvanized, Painted
Standards Compliance
- China: YB/T 4001.1-2007
- USA: ANSI/NAAMM(MBG531-88)
- UK: BS4592-1987
- Australia: AS1657-1985
Technical Specifications
| Series | Pitch of Bearing bar | Pitch of Cross bar | Specifications of Bearing Bar (Width x Thickness) |
|---|---|---|---|
| 1 | 30 | 100 | WA253/1 | WA253/1 | WA254/1 | WA404/1 | WA205/1 | WA255/1 |
| 50 | WB253/1 | WB253/1 | WB254/1 | WB404/1 | WB205/1 | WB255/1 | ||
| 2 | 40 | 100 | WA253/2 | WA323/2 | WA254/2 | WA404/2 | WA205/2 | WA255/2 |
| 50 | WB253/2 | WB323/2 | WB254/2 | WB404/2 | WB205/2 | WB255/2 | ||
| 3 | 60 | 50 | WB53/3 | WB323/3 | WB254/3 | WB404/3 | WB205/3 | WB255/3 |
Product Summary
HDG Anti-Slip International Standard Steel Grating Product Description Steel bar grating has a vast amount of uses ranging from flooring and stairs to bridges and sewage drain covers. It is a smart choice for flooring and stairs in work areas where slipping and falling are a major concern, such as ...
