Product Details:
Place of Origin: China
Brand Name: GNEE
Certification: SGS
Payment & Shipping Terms:
Minimum Order Quantity: 10 square meter
Price: Negotiable
Packaging Details: Sea-worthy packing, ie wooden or steel tray with steel strip,etc
Delivery Time: 5-9 working days
Payment Terms: Negotiable
Supply Ability: 100 ton/week

Steel Bar Grating Used in Floors, Walkways, Platforms and Bridge Decking Type SL Swage-Locked

Description
Highlight:

steel bar grating for walkways

,

swage-locked steel grating

,

platform steel grating with warranty

Steel Bar Grating Used in Floors, Walkways, Platforms and Bridge Decking Type SL Swage-Locked
Manufacturing Process

Our hot dip galvanized machine press welded steel gratings are manufactured through a rigorous production process:

  • Step 1: Materials Preparation - Bearing bars and cross bars are prepared for welding.
  • Step 2: Bearing Bars Placement - Bearing bars are placed into a specialized work-holding device.
  • Step 3: Pressure Welding - Cross bars are cold pressed into bearing bars at high pressure and resistance welded under high temperature.
  • Step 4: Flush Trimming for Edges - Excess cross bar material is removed from grating panel edges.
  • Step 5: Cutting to Size and Shape - Panels are cut according to buyer specifications.
  • Step 6: Banding for Open Ends - Open ends are welded closed using banding bars matching bearing bar specifications.
  • Step 7: Hot Dip Galvanizing - Final panels receive a zinc coating (minimum 65μm) for corrosion resistance lasting 15-30 years in harsh conditions.
Steel Bar Grating Used in Floors, Walkways, Platforms and Bridge Decking Type SL Swage-Locked 0
Product Specifications
Type of Bearing Bars Size of Bearing Bars (mm, Depth x Thickness) Size of Cross Bars (mm) Pitch of Rectangular Holes (mm)
Rectangular Flat Bars 25 × 2 8 x 8 30x100, 40x100, 60x100
25 × 3 8 x 8 30x100, 40x100, 60x100
25.4 × 4.76 8 x 8 30x100, 40x100, 60x100
30 × 5 8 x 8 30x100, 40x100, 60x100
65 x 5 8 x 8 30x100, 40x100, 60x100
I-Shaped Steel Bars 26.8 × 6.25 8 x 8 30x100, 40x100, 60x100
T-Shaped Steel Bars 32 x 60 8 x 8 30x100, 40x100, 60x100
Steel Bar Grating Used in Floors, Walkways, Platforms and Bridge Decking Type SL Swage-Locked 1
Competitive Advantages

Our steel bar grating products dominate the market due to superior product features and company strengths:

Product Advantages
  • Appropriate Materials - Mild carbon steel and stainless steel for durability in all environments
  • High Percentage of Open Area (50-80%) - Allows unhindered passage of light, air, and liquids
  • High Strength-to-Weight Ratio - Supports loads from pedestrian traffic to heavy vehicles
  • Product Flexibility - Custom fabrication to suit exact application requirements
  • Economy - Shop-fabricated for immediate installation and service
  • Maintenance-Free - Excellent drainage and debris passage reduces maintenance needs
Steel Bar Grating Used in Floors, Walkways, Platforms and Bridge Decking Type SL Swage-Locked 2
