A325 High Quality Carbon Steel Weld Bar Metal Grate HDG Anti-Slip International Standard Steel Grating for Steel Platform/Walkway Mesh Panel/Flooring
Place of Origin:China
Brand Name:GNEE
Certification:SGS
Price:Negotiable
Payment Terms:Negotiable
Tags:
Product Details
Highlight:
carbon steel weld bar grate
,HDG anti-slip steel grating
,international standard steel platform grating
Product Description
A325 High Quality Carbon Steel Weld Bar Metal Grate HDG Anti-Slip International Standard Steel Grating
Product Description
Steel grating is welded bearing steel bars and cross twisted bars according to required pitch space between steel bars by steel grating welding machines. It is a grid building material designed for steel platforms, walkway mesh panels, and flooring applications.
Key Features
- Made using high quality standard steel materials with excellent hardness and high tensile strength
- Extremely strong, durable, and corrosion resistant
- Superior anti-slip performance
- Available in various spacing pitches, thicknesses, and heights to meet different load bearing requirements
Surface Finishing
Standard steel grating is hot-dipped galvanized. Zinc coating can be customized according to client requirements. Available as hot-dip galvanized steel grating or stainless steel gratings with beautiful surface appearance and excellent performance for industrial construction projects.
Materials
- Low Carbon Steel Smooth Flat Bars, Serrated Bars, I-Shaped Steel Bars
- Steel Twisted Square Cross Bars, Steel Round Cross Bars
- Stainless Steel 304 Grade Flat Bars, Stainless Steel 316 Grade Flat Bars
Product Specifications
| Series | Pitch of Bearing Bar | Pitch of Cross Bar | Specifications of Bearing Bar (Width x Thickness) |
|---|---|---|---|
| 1 | 30 | 100 | WA253/1 | WA253/1 | WA254/1 | WA404/1 | WA205/1 | WA255/1 |
| 50 | WB253/1 | WB253/1 | WB254/1 | WB404/1 | WB205/1 | WB255/1 | ||
| 2 | 40 | 100 | WA253/2 | WA323/2 | WA254/2 | WA404/2 | WA205/2 | WA255/2 |
| 50 | WB253/2 | WB323/2 | WB254/2 | WB404/2 | WB205/2 | WB255/2 | ||
| 3 | 60 | 50 | WB53/3 | WB323/3 | WB254/3 | WB404/3 | WB205/3 | WB255/3 |
| Series | Pitch of Bearing Bar | Pitch of Cross Bar | Specifications of Bearing Bar (Width x Thickness) |
|---|---|---|---|
| 1 | 30 | 100 | WA325/1 | WA405/1 | WA455/1 | WA505/1 | WA555/1 | WA605/1 |
| 50 | WB325/1 | WB405/1 | WB455/1 | WB505/1 | WB555/1 | WB605/1 | ||
| 2 | 40 | 100 | WA325/2 | WA405/2 | WA455/2 | WA505/2 | WA555/2 | WA605/2 |
| 50 | WB325/2 | WB405/2 | WB455/2 | WB505/2 | WB555/2 | WB605/2 | ||
| 3 | 60 | 50 | WB325/3 | WB405/3 | WB455/3 | WB505/3 | WB555/3 | WB605/3 |
Product Summary
A325 High Quality Carbon Steel Weld Bar Metal Grate HDG Anti-Slip International Standard Steel Grating Product Description Steel grating is welded bearing steel bars and cross twisted bars according to required pitch space between steel bars by steel grating welding machines. It is a grid building ...
