Plain Style and Serrated Style Pressure Locked Steel Grating with I Bar Type for Industrial Platforms

Plain Style and Serrated Style Pressure Locked Steel Grating with I Bar Type for Industrial Platforms
Plain Style and Serrated Style Pressure Locked Steel Grating with I Bar Type for Industrial Platforms Plain Style and Serrated Style Pressure Locked Steel Grating with I Bar Type for Industrial Platforms Plain Style and Serrated Style Pressure Locked Steel Grating with I Bar Type for Industrial Platforms

Large Image :  Plain Style and Serrated Style Pressure Locked Steel Grating with I Bar Type for Industrial Platforms

Product Details:
Brand Name: Gnee
Certification: ISO9001
Payment & Shipping Terms:
Minimum Order Quantity: 2PCS
Packaging Details: Fix with metal belt Packing with pallet ,outside wrap with waterproof plastic film Finial in container
Delivery Time: Shipped in 20 days after payment
Supply Ability: 300000 Square Meter/Square Meters per Month
Contact Now

Plain Style and Serrated Style Pressure Locked Steel Grating with I Bar Type for Industrial Platforms

Description
Highlight:

Plain Style Steel Grating

,

Serrated Style Steel Grating

,

I Bar Type Steel Grating

Industrial Pressure Locked Steel Grating for Operating Platform Flooring
Our hot dip galvanized steel grating is available in three styles: Plain Style, Serrated Style, and I Bar Type. These durable solutions are ideal for steel structure platforms, stair treads, sidewalks, drainages, and well covers. We offer both standard and custom-designed steel grating to meet specific project requirements.
Product Specifications
Product Name Steel Grating
Material Low Carbon Steel
Surface Treatment Black, Hot dip galvanized, Painted, Powder coated
Type Plain/I/serrated style
Height of Bearing Bar 1'', 1 1/4'', 1 1/2'', 2'' (20, 25, 30, 32, 40, or 50mm) etc.
Thickness of Bearing Bar 1/8'', 3/16'', 1/4'' (3, 4, or 5mm) etc
Pitch of Bearing Bar 1''-4'' (25, 30, 35, 40, 50, or 60mm)
Pitch of Cross Bar 2''-4'' (30, 40, 50, or 100mm)
Diameter of Cross Bar 5x5, 6x6, or 8x8mm
Application Industrial Platform, walkway
Plain Style and Serrated Style Pressure Locked Steel Grating with I Bar Type for Industrial Platforms 0
Welded Bar Grating Details
Welded bar grating, also known as metal open bar grating, is available in smooth and serrated varieties. While smooth steel bar grating is more common, serrated grating provides superior skid resistance. Manufactured from low carbon steel, stainless steel, or aluminum, this grating is created by bonding slotted bars under hydraulic pressure. Its strength and durability make it ideal for industrial and commercial applications including stair treads, platforms, walkways, and covers.
Swage locked grating, primarily made of aluminum or stainless steel bars, features cross bars inserted into pre-punched bearing bars and locked under hydraulic pressure. Available with rectangular, T, or I bars, the I bar variant offers a lighter and more economical solution.
Plain Style and Serrated Style Pressure Locked Steel Grating with I Bar Type for Industrial Platforms 1
Plain Style and Serrated Style Pressure Locked Steel Grating with I Bar Type for Industrial Platforms 2
Plain Style and Serrated Style Pressure Locked Steel Grating with I Bar Type for Industrial Platforms 3

Tag:

press lock grating,

welded bar grating,

pressure locked grating
