Galvanized Steel Grating 1000x6000mm for Car Wash Flooring and Industrial Platforms

Brand Name:Gnee

Minimum Order Quantity:2PCS

Supply Ability:300000 Square Meter/Square Meters per Month

Product Details

Highlight:

Galvanized Steel Grating

1000x6000mm Metal Grating

Car Wash Flooring Steel Grating

Product Description

Galvanized Scupper Drain Grating - Car Wash Steel Grate Flooring

What is Steel Grating?

Steel grating, also known as steel platform grating, is manufactured by arranging bearing bars and cross bars in a flat-steel weft pattern. The components are welded together using high-pressure resistance welding technology, followed by cutting, notching, opening, and overlocking processes to create finished products that meet specific customer requirements.

Steel Grating Specifications

Standard panel sizes available (black grating): 1000x5800mm or 1000x6000mm

Bearing Bar Pitch	Cross Bar Pitch	Load Steel Size (Width × Thickness)	Product Code
30	100	20×3, 25×3, 32×3, 40×3, 20×5, 25×5	G203/30/100, G253/30/100, G323/30/100, G403/30/100, G205/30/100, G255/30/100
30	50	20×3, 25×3, 32×3, 40×3, 20×5, 25×5	G203/30/50, G253/30/50, G323/30/50, G403/30/50, G205/30/50, G255/30/50
40	100	20×3, 25×3, 32×3, 40×3, 20×5, 25×5	G203/40/100, G253/40/100, G323/40/100, G403/40/100, G205/40/100, G255/40/100
40	50	20×3, 25×3, 32×3, 40×3, 20×5, 25×5	G203/40/50, G253/40/50, G323/40/50, G403/40/50, G205/40/50, G255/40/50
60	50	25×3, 32×3, 40×3, 20×5, 25×5	G253/60/50, G323/60/50, G403/60/50, G205/60/50, G255/60/50

Bearing Bar Pitch	Cross Bar Pitch	Load Steel Size (Width × Thickness)	Product Code
30	100	32×5, 40×5, 45×5, 50×5, 55×5, 60×5	G325/30/100, G405/30/100, G455/30/100, G505/30/100, G555/30/100, G605/30/100
30	50	32×5, 40×5, 45×5, 50×5, 55×5, 60×5	G325/30/50, G405/30/50, G455/30/50, G505/30/50, G555/30/50, G605/30/50
40	100	32×5, 40×5, 45×5, 50×5, 55×5, 60×5	G325/40/100, G405/40/100, G455/40/100, G505/40/100, G555/40/100, G605/40/100
40	50	32×5, 40×5, 45×5, 50×5, 55×5, 60×5	G325/40/50, G405/40/50, G455/40/50, G505/40/50, G555/40/50, G605/40/50
60	50	32×5, 40×5, 45×5, 50×5, 55×5, 60×5	G325/60/50, G405/60/50, G455/60/50, G505/60/50, G555/60/50, G605/60/50

Steel Grating Platform Features

Bearing Bar Types

Flat bar
I bar
Serrated bar

Cross Bar Types

Twisted bar
Round bar
Flat bar

Production Processes

Welded
Pressure locked

Surface Treatments

Self-colour
Galvanized
Painted

Applications

Platforms
Walkways & Flooring
Trench Covers
Steel Stair Treads
Suspended Ceilings
Barrier Fences

Galvanized steel grating installation in car wash facility

Close-up view of steel grating surface and drainage pattern

Steel grating specifications and dimensional details

Product Summary

Galvanized Scupper Drain Grating - Car Wash Steel Grate Flooring What is Steel Grating? Steel grating, also known as steel platform grating, is manufactured by arranging bearing bars and cross bars in a flat-steel weft pattern. The components are welded together using high-pressure resistance ...
