Hot DIP Galvanized Steel Grating with Bearing Bar Pitch 30-60mm and I-Section Type Bearing Bar for Heavy Duty Flooring

Hot DIP Galvanized Steel Grating with Bearing Bar Pitch 30-60mm and I-Section Type Bearing Bar for Heavy Duty Flooring
Hot DIP Galvanized Steel Grating with Bearing Bar Pitch 30-60mm and I-Section Type Bearing Bar for Heavy Duty Flooring Hot DIP Galvanized Steel Grating with Bearing Bar Pitch 30-60mm and I-Section Type Bearing Bar for Heavy Duty Flooring Hot DIP Galvanized Steel Grating with Bearing Bar Pitch 30-60mm and I-Section Type Bearing Bar for Heavy Duty Flooring

Large Image :  Hot DIP Galvanized Steel Grating with Bearing Bar Pitch 30-60mm and I-Section Type Bearing Bar for Heavy Duty Flooring

Product Details:
Brand Name: Gnee
Payment & Shipping Terms:
Minimum Order Quantity: 2PCS
Packaging Details: Fix with metal belt Packing with pallet ,outside wrap with waterproof plastic film Finial in container
Delivery Time: Shipped in 20 days after payment
Supply Ability: 300000 Square Meter/Square Meters per Month
Contact Now

Hot DIP Galvanized Steel Grating with Bearing Bar Pitch 30-60mm and I-Section Type Bearing Bar for Heavy Duty Flooring

Description
Highlight:

Hot DIP Galvanized Steel Grating

,

Bearing Bar Pitch 30-60mm Bar Grating

,

I-Section Type Bearing Bar Metal Grating

Galvanized Bearing Bar Pitch Drain Perforated Steel Grating
Steel grating, also known as steel grid or bar grating, is a versatile and robust flooring solution designed for industrial, commercial, and architectural applications. Made from high-quality carbon or stainless steel, our steel grating features a lightweight yet durable design that ensures excellent load-bearing capacity and long-lasting performance.
Product Specifications
Bearing Bar Specifications
  • Plain & Serrated Type: 20 x 3 to 100 x 10 mm
  • I-Section Type: 25 x 5 x 3, 32 x 5 x 3, 38 x 5 x 3, 40 x 5 x 3, 50 x 5 x 3, 50 x 7 x 4, 55 x 7 x 4, 60 x 7 x 4, 65 x 7 x 4, 70 x 7 x 4, 75 x 7 x 4 mm
Bearing Bar Pitch (Center to Center)
  • Metric: 12.5, 15, 25, 30, 30.16, 32.5, 34, 40, 41.25, 45, 50, 60, 60.32, 80, 100 mm (30, 40, 60mm recommended)
  • American Standard: 1" x 3/16", 1 1/4" x 3/16", 1-1/2" x 3/16", 1" x 1/4", 1-1/4" x 1/4", 1 1/2" x 1/4" (19-w-4)
Cross Bar Pitch (Center to Center)
  • 38.1, 40, 50, 60, 76, 80, 90, 100, 101.6, 102, 135 mm (50, 100mm recommended)
Material Options
  • Mild Steel (Low Carbon Steel)
  • Stainless Steel
Surface Treatments
  • Untreated
  • Painting
  • Hot DIP Galvanizing
International Standards Compliance
  • China: YB/T4001-1998
  • USA: ANSI/NAAMM (MBG531-88)
  • UK: BS4592-1987
  • Australia: AS1657-1985
  • Japan: JJS
Material 1. Carbon Steel Q235
2. Stainless Steel 304 / 316
Type Press locked / Flat bar / Serrated bar / I Bar
Bearing Bar Size 20 x 3 to 100 x 9 mm; I-section: 25 x 5 x 3, 32 x 5 x 3, 38 x 5 x 3, 40 x 5 x 3, 50 x 5 x 3, 50 x 7 x 4, 55 x 7 x 4, 60 x 7 x 4, 65 x 7 x 4, 70 x 7 x 4, 75 x 7 x 4 mm
Bearing Bar Pitch 12.5 to 100 mm (30, 40, 60mm recommended)
American standard available
Cross Bar Pitch 18.5 to 101.6 mm (50, 100mm recommended)
American standard available
Surface Treatment Untreated / Painting / Hot Dip Galvanizing
Steel Standard China GB700-88 / America ASTM (A36) / Britain ASTM (A36)
HDG Standard China GB/T13912-92 / America ASTM (A123) / Britain BS729
Quality Standard China YB/T4001-1998
America ANSI/NAAMM (MBG531-88)
Britain BS4592-1987
Australia AS1657-1992
Product Images
Hot DIP Galvanized Steel Grating with Bearing Bar Pitch 30-60mm and I-Section Type Bearing Bar for Heavy Duty Flooring 0 Hot DIP Galvanized Steel Grating with Bearing Bar Pitch 30-60mm and I-Section Type Bearing Bar for Heavy Duty Flooring 1 Hot DIP Galvanized Steel Grating with Bearing Bar Pitch 30-60mm and I-Section Type Bearing Bar for Heavy Duty Flooring 2
