Heavy Duty Load Bearing Galvanized Steel Grating with Serrated Bearing Bar in Customizable Sizes

Heavy Duty Load Bearing Galvanized Steel Grating with Serrated Bearing Bar in Customizable Sizes
Heavy Duty Load Bearing Galvanized Steel Grating with Serrated Bearing Bar in Customizable Sizes Heavy Duty Load Bearing Galvanized Steel Grating with Serrated Bearing Bar in Customizable Sizes Heavy Duty Load Bearing Galvanized Steel Grating with Serrated Bearing Bar in Customizable Sizes Heavy Duty Load Bearing Galvanized Steel Grating with Serrated Bearing Bar in Customizable Sizes

Large Image :  Heavy Duty Load Bearing Galvanized Steel Grating with Serrated Bearing Bar in Customizable Sizes

Product Details:
Brand Name: Gnee
Payment & Shipping Terms:
Minimum Order Quantity: 2PCS
Packaging Details: Fix with metal belt Packing with pallet ,outside wrap with waterproof plastic film Finial in container
Delivery Time: Shipped in 20 days after payment
Supply Ability: 300000 Square Meter/Square Meters per Month
Contact Now

Heavy Duty Load Bearing Galvanized Steel Grating with Serrated Bearing Bar in Customizable Sizes

Description
Highlight:

Serrated Bearing Bar Galvanized Steel Grating

,

Customizable Sizes Steel Bar Grating

,

Heavy Duty Load Bearing Metal Grating

Customized Anti-slip Serrated Steel Grating
This serrated steel grating features a scientific structural design optimized for applications requiring high load-bearing capacity and superior appearance. Manufactured through precision slotting, inserting, welding, and finishing processes, it delivers exceptional performance for heavy-duty industrial platforms with enhanced safety factors.
Key Features
  • Serrated bearing bars for superior anti-slip performance
  • High load-bearing capacity for demanding industrial applications
  • Scientific structural design ensuring optimal strength and safety
  • Multiple surface treatment options: hot-dip galvanizing, painting, or dipping
  • Customizable dimensions to meet specific project requirements
Product Specifications
Parameter Specifications
Product Name Customized Anti-slip Serrated Steel Grating
Material Options Mild Steel (Low Carbon Steel), S235, S275JR, A36, or Stainless Steel SS304, SS316
Surface Treatment Hot-dipped galvanized, polished, or untreated
Grate Size Customized to customer requirements
Bearing Bar Dimensions 25x3, 25x4, 30x3, 30x4, 30x5, 32x5, 40x5, 50x5,...75x10mm
Bearing Bar Pitch 12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 34.3, 35, 40, 41, 60mm
Cross Bar Pitch 38, 50, 76, 100, 101.6mm or custom
Standard Specifications Table
Bearing Bar Pitch (mm) Cross-bar Pitch (mm) Bearing Bar Specification (width x thickness)
30 100 G203/30/100, G253/30/100, G323/30/100, G403/30/100, G205/30/100, G255/30/100
50 G203/30/50, G253/30/50, G323/30/50, G403/30/50, G205/30/50, G255/30/50
40 100 G203/40/100, G253/40/100, G323/40/100, G403/40/100, G205/40/100, G255/40/100
50 G203/40/50, G253/40/50, G323/40/50, G403/40/50, G205/40/50, G255/40/50
60 50 G253/60/50, G403/60/50, G205/60/50, G255/60/50
Bearing Bar Pitch (mm) Cross-bar Pitch (mm) Bearing Bar Specification (width x thickness)
30 100 G325/30/100, G405/30/100, G455/30/100, G505/30/100, G555/30/100, G605/30/100
50 G325/30/50, G405/30/50, G455/30/50, G505/30/50, G555/30/50, G605/30/50
40 100 G325/40/100, G405/40/100, G455/40/100, G505/40/100, G555/40/100, G605/40/100
50 G325/40/50, G405/40/50, G455/40/50, G505/40/50, G555/40/50, G605/40/50
60 50 G325/60/50, G405/60/50, G455/60/50, G505/60/50, G555/60/50, G605/60/50
Customized sizes are supported to meet specific project requirements.
Heavy Duty Load Bearing Galvanized Steel Grating with Serrated Bearing Bar in Customizable Sizes 0 Heavy Duty Load Bearing Galvanized Steel Grating with Serrated Bearing Bar in Customizable Sizes 1 Heavy Duty Load Bearing Galvanized Steel Grating with Serrated Bearing Bar in Customizable Sizes 2
