Hot-Dip Galvanized Steel Grating with Anti-Slip Design for Heavy-Duty Load Capacity

Description

Heavy-Duty Light Steel Platform with Anti-Slip Grating Design

Hot-Dip Galvanized Steel Grating, also known as hot-dip galvanized steel grating, is a grid-shaped building material made of low carbon steel flat steel and twisted square steel welded horizontally and vertically. Hot-dip galvanized steel grating has strong impact resistance, excellent corrosion resistance, heavy load capacity, elegant appearance, and superior performance in municipal roadbed and steel platform construction projects.

Due to its exceptional cost performance, hot-dip galvanized steel grating is widely used in construction projects of paved ditch roads on new and old roadbeds. The surface undergoes special hot-dip galvanizing treatment, providing stable chemical and physical properties that resist corrosion and oxidation from air and microorganisms. This significantly enhances trench load capacity and prevents collapse.

The hot-dip galvanized steel grating with a 3 cm spacing between flat steel bars offers greater impact resistance and maximum span characteristics. Service life typically ranges from 40 to 50 years. Without damaging factors, hot-dip galvanized steel grating serves as an excellent steel frame structure and load-bearing platform.

  • Nice welding flat bar mild steel high strength G300 grade welded steel grating
  • Hot Galvanized Heavy Duty Floor Grating Steel Grating
  • High strength Mild Metal Hot Dipped Galvanized Catwalk Steel Grating
  • Mild steel Galvanized Steel Grating for Floor and Trench
  • Light Steel Structure Platform galvanized steel Grating, Handrails and Treads
Hot-Dip Galvanized Steel Grating with Anti-Slip Design for Heavy-Duty Load Capacity 0
Product Specifications

Light Steel Structure Platform galvanized steel Grating, Handrails and Treads

Bearing Bar Pitch Cross Bar Pitch Load Steel Size (Width × Thickness)
20×3 25×3 32×3 40×3 20×5 25×5
30 100 G203/30/100 G253/30/100 G323/30/100 G403/30/100 G205/30/100 G255/30/100
50 G203/30/50 G253/30/50 G323/30/50 G403/30/50 G205/30/50 G255/30/50
40 100 G203/40/100 G253/40/100 G323/40/100 G403/40/100 G205/40/100 G255/40/100
50 G203/40/50 G253/40/50 G323/40/50 G403/40/50 G205/40/50 G255/40/50
60 50 - G253/60/50 G253/60/50 G403/60/50 G205/60/50 G255/60/50
Bearing Bar Pitch Cross Bar Pitch Load Steel Size (Width × Thickness)
32×5 40×5 45×5 50×5 55×5 60×5
30 100 G325/30/100 G405/30/100 G455/30/100 G505/30/100 G555/30/100 G605/30/100
50 G325/30/50 G405/30/50 G455/30/50 G505/30/50 G555/30/50 G605/30/50
40 100 G325/40/100 G405/40/100 G455/40/100 G505/40/100 G555/40/100 G605/40/100
50 G325/40/50 G405/40/50 G455/40/50 G505/40/50 G555/40/50 G605/40/50
60 50 G325/60/50 G405/60/50 G455/60/50 G505/60/50 G555/60/50 G605/60/50

Walk Steel Grating - Light Steel Structure Platform galvanized steel Grating, Handrails and Treads

Bearing Bar Type Flat bar I bar Serrated bar
Cross Bar Type Twisted bar Round bar Flat bar
Production Process Welded Pressure locked
Surface Treatment Self-colour Galvanized Painted
Application Platform Walkway & Floor Trench cover
Steel stair treads Suspended ceiling Barrier fence
Hot-Dip Galvanized Steel Grating with Anti-Slip Design for Heavy-Duty Load Capacity 1
Frequently Asked Questions
Q: How long does galvanized steel grating last?
A: 20+ years in normal environments; 10-15 years in high-corrosion areas.
Q: What are the advantages of steel grating?
A: High strength, light weight, drainage/ventilation, slip resistance, low maintenance.
Q: Where is steel grating commonly used?
A: Factories, power plants, wastewater plants, ports, walkways, stair treads, trench covers.
Q: How to choose the right load capacity?
A: Match load class to usage: pedestrian (light), equipment (medium), forklifts (heavy).
Q: Can you customize steel grating?
A: Yes—custom dimensions, shapes, cutouts, finishes, and accessories (clips, kick plates).
