Anti Slip Galvanized Steel Grating with 100mm Cross Bar Pitch for Industrial Flooring
Basic Properties
Brand Name:
Gnee
Certification:
ISO9001,SGS
Model Number:
BS-04
Trading Properties
Minimum Order Quantity:
10 square meter
Supply Ability:
100 ton/week
Product Summary
Anti Slip Galvanized Steel Grating ISO SGS Certificate 100mm Cross Bar Pitch Heavy Duty Anti Slip Welded Steel Gratings With ISO SGS Certificate Steel Grating is the workhorse of the industrial flooring market and has served industry for decades. Strong and durable with an exceptional strength-to...
Product Details
Highlight:
steel walkway grating
,galvanised steel mesh walkway
Bear Bar:
25 X 5 X 3,75 X 7 X 4, Etc
Material:
Galvanized Sheet, A36
Cross Bar Pitch:
100mm
Bearing Bar Pitch:
15,20,25,30,33,35,38,40,50,60,80,90mm
Market:
USA, AUS, UK, Kuwait, And So On
Certificate:
ISO9001:2008, SGS
Product Description
Anti Slip Galvanized Steel Grating ISO SGS Certificate 100mm Cross Bar Pitch
Heavy Duty Anti Slip Welded Steel Gratings With ISO SGS Certificate
Steel Grating is the workhorse of the industrial flooring market and has served industry for decades. Strong and durable with an exceptional strength-to-weight ratio, metal bar grating can be easily fabricated to nearly any configuration. The high percentage of open area makes bar grating practically maintenance-free and all products are fully recyclable.
Grating Standardizations
| Countries | National Standards for Grating | Materials | Galvanizing Standards |
|---|---|---|---|
| China | YB/T 4001.1-2007 | GB 700-88 | GB/T13912-2002 |
| America | ANSI/NAAMM(MBG531-00) | ASTM(A36) | ASTM(A123) |
| Britain | BS4592-1995 | BS4360(43A) | BS729 |
| Australia | AS1657-1992 | AS3679 | AS1650 |
Steel Grating Specifications
- Bearing Bar (Load Bar) Specifications (mm): The specification of plain type and serrated type bearing bar is 25 x 3 to 100 x 8; The specification of I-section type is 25 x 5 x 3, 32 x 5 x 3, 38 x 5 x 3, 40 x 5 x 3, 50 x 5 x 3, 50 x 7 x 4, 55 x 7 x 4, 60 x 7 x 4, 65 x 7 x 4, 70 x 7 x 4, 75 x 7 x 4, etc.
- Bearing Bar Pitch (center to center): 12.5, 25, 30, 30.16, 32.5, 34, 40, 41.25, 45, 50, 60, 60.32, 80, 100 mm etc, also be according to client's requirement and 30, 40, 60mm are recommended, America standard is available <1'' x 3/16'', 1 1/4'' x 3/16'', 1-1/2'' x 3/16'', 1'' x 1/4'', 1-1/4'' x 1/4'', 1 1/2'' x 1/4''(19-w-4) and so on. >
- Material: Mild Steel (Low Carbon Steel) or Stainless Steel
- Surface Treatment: Untreated, Painting or Hot DIP Galvanizing
- Steel grating standards: A) China: YB/T4001-1998 B) USA: ANSI/NAAMM (MBG531-88) C) UK: BS4592-1987 D) Australia: AS1657-1985 E) Japan: JJS
Common Specifications
| Product Name | Steel grating |
| Material | Low carbon steel / Stainless steel |
| Grade | CN: Q235, Q345, USA: A36, UK: 43A |
| Standard | CN: YB/T4001-1998, USA: ANSI/NAAMM, UK: BS4592-1987, AUS1657-1988, JJS |
| Certification | CE, GOST, ISO9001, ISO14001, HSE |
| Bearing bar size | 20X5, 25X3, 25X4, 25X5, 30X3, 30X4, 30X5, 32X3, 32X5, 40X5, 50X4... 75X8, 100X8mm, etc |
| Bearing bar pitch | 20,25,30,32.5,34.3,40,50,60,62,65mm |
| Bearing bar type | Plain, Serrated (tooth-like), I bar (I section), Serrated-I |
| Cross bar size | 5X5, 6X6, 8X8mm (twisted bar)/5, 6, 8mm ( round bar) |
| Cross bar pitch | 40, 50, 60, 65, 76, 100, 101.6, 120, 130mm, etc. |
| Panel size | 3x20ft,3x24ft,3x30ft,5800x1000,6096x1000,6400x1000, as request |
| Surface treatment | Untreated, hot DIP galvanized, cold DIP galvanized, painted, powder coated, pickling, electrolytic polishing, or as customers' requirement. |
| Galvanization Standard | CN: GB/T13912, USA: ASTM (A123), UK: BS729 |
| Color | Silver/Black |
| Application | petroleum and chemical, port, power, transportation, papermaking, medicine, steel and iron, food, municipality, real estate, manufacturing |
Application Scenarios
Frequently Asked Questions
Q: Are you trading company or manufacturer?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? Is it free or extra?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment?
A: Payment, 30% T/T in advance, balance before shippment.
