2mm Thick 41% Open Rating Stainless Steel Perforated Metal Mesh and Perforated Steel Sheet

Large Image : 2mm Thick 41% Open Rating Stainless Steel Perforated Metal Mesh and Perforated Steel Sheet

Product Details:

Brand Name:	Gnee
Certification:	ISO9001:2008
Model Number:	PMS

Payment & Shipping Terms:

Minimum Order Quantity:	2pcs
Packaging Details:	The packing usually is pallet or wooden box to avoid damage or deformation to the aluminum product.we can packaging according to your requirement.
Delivery Time:	8DAYS
Payment Terms:	L/C,T/T
Supply Ability:	2000TONS/MONTH

Contact Now

2mm Thick 41% Open Rating Stainless Steel Perforated Metal Mesh and Perforated Steel Sheet

Description

Material:	Stainless Steel	Color:	Sliver, Red,green.etc
Length:	1000mm~6000mm Or Customized	Width:	1.5m
Thickness:	0.3~8mm	Widthness:	1000mm~2000mm Or Customized
Highlight:	perforated stainless steel plate , perforated steel mesh

2mm Thick Perforated Steel Mesh, 41% Open Rating Black Perforated Iron Sheet

Product Overview

2mm thickness perforated metal mesh with 41% open rating, manufactured from black Q235 steel. This versatile perforated sheet offers excellent performance characteristics for various industrial applications.

Key Features

Material: Premium raw materials including stainless steel, iron, galvanized metal, and aluminum sheets
Hole Patterns: Round, rectangular, square, triangle, diamond, hexagonal, cross, slotted, and custom patterns
Surface Treatment: Galvanized finish available
Opening Area: Customizable to specific requirements

Product Characteristics

Various hole pattern options available
Accurate hole sizing with excellent bending resistance and corrosion resistance
Easy to process and install with good sound absorption properties
Durable construction ensuring long service life
Attractive appearance with wide range of thickness options

Applications

Noise control barrier walls for generator rooms and factories
Building ceiling and wall sound-absorbing materials
Architectural elements including stairs, balconies, tables, and chairs
Environmental protection decorative panels

Packaging

Available in roll type and flat type configurations. Standard packaging includes wooden pallets with plastic film wrapping. Custom packaging options available upon request.

Technical Specifications

Aperture (mm)	Pitch (mm)	Opening Rate (%)	0.4mm	0.5mm	0.8mm	1.0mm	1.2mm	1.5mm
1.5	3	23%		**	**	**	**
1.8	3.5	24%		**	**	**	**	**
2	3	40%		**	**	**
2.5	4	23%		**	**	**	**	**
2.5	3.5	46%		**	**	**	**	**
2.5	4	35%		**	**	**	**	**
2.5	4.5	28%		**	**	**	**	**
3	5	23%		**	**	**	**	**
3	5	33%		**	**	**	**	**
3.5	6	23%		**	**	**	**	**
4	5	44%		**	**	**
4	5	58%		**	**	**	**	**
4	6	44%		**	**	**	**	**
5	8	23%		**	**	**	**	**
5	7	46%		**	**	**	**	**
5	8	35%		**	**	**	**	**
5	10	23%		**	**	**	**	**
6	25	4%		**	**	**	**	**
6	8.5	45%		**	**	**	**	**
6	9	40%		**	**	**	**	**
7	10	33%				**	**	**
8	10	44%				**	**	**
8	11	48%				**	**	**
8	12	40%				**	**	**
10	15	26%				**	**	**
10	13	54%				**	**	**
10	14	46%				**	**	**
10	15	40%				**	**	**
10	18	28%	**	**	**	**	**	**

Product Image

Frequently Asked Questions

Where is steel grating commonly used?

Used in walkways, platforms, stair treads, drainage covers, industrial flooring, and catwalks.

Is steel grating slip-resistant?

Yes, serrated grating or coated finishes improve slip resistance.

Can steel grating be used outdoors?

Yes, especially galvanized or stainless steel grating, which resists corrosion.

How long does galvanized steel grating last?

Typically 15-30 years depending on environment and maintenance.

Is steel grating fire-resistant?

Yes, steel grating is non-combustible and suitable for high-temperature applications.

What is the standard size of steel grating panels?

Standard panels are 1m x 6m or 1.2m x 6m, but custom sizes are common.
