0.7mm Thickness 4mm Hole Galvanized Perforated Metal Mesh for Screening Filtering

Place of Origin:China

Brand Name:GNEE

Certification:SGS

Price:Negotiable

Payment Terms:Negotiable

Product Details

Highlight:

galvanized perforated metal mesh

0.7mm thick perforated metal mesh

4mm hole perforated metal filter

Product Description

0.7mm Thickness 4mm Hole Galvanized Perforated Metal Mesh for Screening Filtering

Product Description

Perforated metal mesh is typically manufactured using galvanized steel, stainless steel, copper steel, aluminum steel, nickel steel, and alloy steel materials. Our advanced CNC equipment ensures products are made to exact specifications with high precision, minimal error, and superior quality. We offer punching diameters ranging from 0.3mm to 100mm, with thickness equal to diameter (e.g., 0.5mm thickness can punch 0.5mm diameter holes).

Main Parameters

Name	Perforated Mesh / Perforated Sheet / Punching Mesh / Decorative Mesh
Material	Aluminum Sheet, Steel Sheet, Galvanized Sheet, Carbon steel, Copper Nickel, Titanium etc.
Surface Finish	(1) For aluminum material: - Mill finish - Anodized finish (silver only) - Powder coated (any color) - PVDF (any color, smoother surface and longer life span) (2) For iron steel material: - Galvanized: Electric galvanized, Hot-dip galvanized - Powder coated
Sheet size (m)	1x1m, 1x2m, 1.2x2.4m, 1.22x2.44m, etc
Thickness (mm)	2.0mm~10mm, standard: 2.0mm, 2.5mm, 3.0mm
Hole shape	Round, square, diamond, hexagonal, star, flower, etc
Perforation way	Straight perforation, staggered perforation

Galvanized Perforated Metal Mesh for Screening and Filtering

Features

Easy to process with various plate thicknesses, pore sizes, and arrangements available
Beautiful appearance with abrasion-resistant painting or polishing for long service life
Uniform mesh and smooth surface
Low cost and easy to install

Material

The raw material typically consists of stainless steel carbon plate, galvanized plate, and cold rolled coil, among others.

Galvanized Perforated Metal

Galvanized Perforated Metal is manufactured from high-quality low carbon galvanized steel sheets using digital control perforated machines. It features excellent strength-to-weight ratio, wide range of open area percentages, precise hole sizes, and is available in corrosion-resistant materials suitable for both functional and decorative applications.

Product Summary

0.7mm Thickness 4mm Hole Galvanized Perforated Metal Mesh for Screening Filtering Product Description Perforated metal mesh is typically manufactured using galvanized steel, stainless steel, copper steel, aluminum steel, nickel steel, and alloy steel materials. Our advanced CNC equipment ensures ...
